RUBYCON - 10ZL680MEFC8X16 - CAP, ALU ELECT, 680UF, 10V, CAN

Manufacturer:
RUBYCON
Order Code:
1144681
Manufacturer Part No:
10ZL680MEFC8X16

Technical Data Sheet (223.53KB) EN
Technical Data Sheet (223.53KB) EN

Product Information
  • CAP, ALU ELECT, 680UF, 10V, CAN
  • Product Range: RUBYCON - ZL Series
  • Capacitance: 680µF
  • Capacitance Tolerance: ± 20%
  • Diameter: 8mm
  • Height: 16mm
  • Capacitor Terminals: Radial Leaded
  • Lead Spacing: 3.5mm
  • Life Time @ Temperature: 3000 hours @ 105°C
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Voltage Rating: 10V
  • Driftlivslängd: 3000h
  • External Length / Height: 16mm
  • Impedance: 0.056ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • Leakage Current: 68µA
  • No. of Pins: 2
  • Operating Temperature Range: -40°C to +105°C
  • Ripple Current AC: 995mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
  • Series: ZL
  • Terminal Type: Wire Ended
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 10V
Find Similar Products grouped by common attributes View this product in our online or paper catalogue

Catalogue Page:

1286 / UK1

Availability

639 in stock for next working day delivery (UK stock)
79 in stock for next working day delivery (EU stock)
see cut-off times
639 UK Stock: Order before 20:00 (for re-reeled items 16:30) Mon-Fri (excluding National Holidays)
79 European Stock: Order before 17:00 (for re-reeled items 16:30) Mon-Fri (excluding National Holidays)

Price For: 1 Each

Minimum Order Quantity: 1

Order Multiple: 1

Unit Price: £0.28

  1. Qty

Price

Qty List Price
1  - 49 £0.28
50  - 99 £0.27
100  - 499 £0.25
500  - 999 £0.22
1000+  £0.20
